Due to concerns regarding data integrity and potential impact on their process and reputation, the Town of Clifton Park, NY Water Authority decided to replace their old software. The legacy software had issues with intermittent communications and trend archiving, posing a risk to the highly regulated drinking water treatment process.
Thank for you for joining us at WATERCON!
Connect – Aggregate/Transform Visualize - Analyze (Data Is Key)
Built with Industrial DNA
- Real-time connectivity with native drivers to PLCs, OPC, MQTT
- Read and write to any device, SQL database, Process Historian or IT system
- Open and Layered to fit and connect to your current Plant Floor systems
FrameworX is built from Industrial DNA as an Industrial Data Integrator or Datahub, with inherent connectivity to real-time devices, SQL and IIoT, bridging your data gaps. Your applications can access this data allowing you to create event-driven, actionable solutions for decision making now.
Combine OT and IT Standards
Flexible and secure, use and connect OT to IT, in a standard way with SQL, .NET, C#, VB.NET, Python, JavaScript, HTML5, OPC UA, MQTT.
Scaled Small to Unlimited
Affordable licensing, buy small I/O or choose FrameworX Unlimited and get unlimited Clients, Tags, I/O, and Development.
Complete Solution
Includes native PLC drivers, SQL database tools, alarms and events, visualization, .NET scripting, trends, model, and any clients.
Whether it is FrameworX Unlimited or FactoryStudio, you can rest assured connectivity was top of mind. It is part of our industrial DNA.
Complete, Unlimited, Scalable
- FrameworX is our Unlimited version, unlimited Clients, I/O and development, server based with all the tools you need
- FactoryStudio is scalable, by the number of I/O & clients
- Edge HMI scale by I/O, more affordable
- Edge/Gateway embedded device communications and processing at the edge or as flexible secure gateway
For even more flexibility, we also offer our FrameworX Unlimited licensing as perpetual plus maintenance or software as a subscription (SaaS). See our pricing here.
Water & Wastewater Case Studies
Case Study | Water Apps | Water and Wastewater
Modern water treatment facilities can operate sophisticated and sometimes very costly water and wastewater networks and sewage treatment plants, which are usually run by a public utility organization or municipality.
Case Study | Lincoln Water District | Water
Lincoln Water, located in Maine, was in need of upgrading their legacy National Instruments data collection system and were looking for a modern platform to sustain their systems for the future.
Case Study | Water Irrigation
Irrigation Automation Company needed a way to visualize and control real-time data to improve efficiency and performance of pivots out in the field, while allowing farmers the ability to communicate via a mobile device, iPad or iPhone. They searched for a complete software package that provided the necessary connectivity, communications, report generation, and graphic displays all-in-one.
FrameworX Integrated Elements
FrameworX integrated elements that enable the secure and efficient deployment of industrial applications such as: SCADA, HMI, IIoT, MES and others based on your needs. The built-in FactoryStudio® functionality includes
Real-Time Tags
Tags, Assets and Templates are the core components of the real-time data. FrameworX has a built-in real-time, event-driven, in-memory database, that manages the tags, assets and events in the application.
Databases and SQL
The Dataset Module provides an easy-to-use interface to any external Database or Process Historian (SQL Server, Oracle, Access, PI, etc), XML, CSV, or text files with access to SQL queries, tables and SPs. Native SQLite is included with FX installation.
Trend and SQL Historian
Log real-time to internal SQL or external databases, like SQL Server, MS Azure, or Oracle, or the built-in SQL. Advanced trend and visualization and annotation features. Combine Historian curves with any SQL database queries.
Scripts and .NET
You can create powerful C#, VB.NET, Python, and JavaScript code. The 100% .NET managed code makes us "intrinsically safe". Intellisense enables direct access objects, including Tags, Alarms, Databases and more.
Devices and Drivers
We include 60+ PLC and other protocols drivers to directly access data from PLCs, Remote IO, bar-codes, RFID and more. We have built-in OPC UA, Modbus and MQTT Client/Broker. And we have a toolkit for any driver.
Graphics Designer
Our Graphics Editor allows for easy creation of rich user interfaces with dynamic animations Resolution independence, isolation from the code, extensibility, and deployment to desktop, thin clients, web and mobile clients. Reusable Smart Symbols and Components.
Diagnostics and More
Tools to show status of running modules, log errors, get warnings and user defined messages, access runtime values and properties, enter simulated values, run in Test protect mode. Accelerate development, assist on startup, isolate, and diagnose.
Reporting and Data Access
Create dynamic reports with our Built-in Report Editor. Use Dynamic Symbols in Reports, save as Text, CSV, XPS, PDF. We also support Web-Services, XML and other data-exchange interfaces to provide data for external reporting tools
Alarms and Notification
Multiple alarm levels for each tag when logging, acknowledgement, displaying, etc. is pre-packaged to simplify the configuration. You can send notifications by email, SMS or voice. The Alarm Module with the Security Tools can provide what’s needed to create FDA 21 CFR Part 11 compliant applications.
Built-In SQL
Includes a full-featured embedded, encrypted SQL engine. Used as local historian with store/forward to any data source, process historians or SQL databases. Store runtime settings or data in tables for reports or display with our built-in DataGrid. Or integrate to any external .NET components.
Security and Redundancy
Dynamically change the project configuration, without stopping the runtime execution. Enable redundancy deployment with a simple check-box configuration. Automatically log project configuration changes, and manage project and product versions seamlessly.
Dashboard Builder
Design responsive dashboards easily with drag and drop panels to display Grids, Trend Charts, Pie Charts, Bar Charts, Gauges, or any Symbol/Custom Symbol. Create your dashboards for both .NET and HTML5 clients from the same engineering environment.
Edge And Gateway On Any Device
FrameworX Edge and IIoT Gateway are Open and can run on many hardware platforms to fit your application
- Any Windows, Linux, and Raspberry PI
- Run on Panel PCs with HMI and Edge
- Customized for most OEM devices
Other FrameworX Functionality
Smart Tag Editing
Integrate to Excel
Built-In Version Control
.NET Classes and Namespaces
Gateway
OSISoft Support
Diagnostics and Commisioning
Vector Graphics
Dream Report Driver
Multiple Monitors
MQTT
Portal
OEM Branding
Python
Wonderware Import
SQL Query Builder
HTML5 and JavaScript
Multi-Languages
Check out our Demo
The Process Plant Demo shows you some of the features you can use in building your own Enterprise SCADA systems.
Traditional Graphics
High Performance Graphics
Animation and State
Alarms and Alarm History
Pop-Up Context Windows
Customizable Trend Charts
Reports
System & Project Information
Traditional Graphics
Traditional Graphics and Powerful Symbols allow you to quickly create and customize your projects of any size.
Build Enterprise software that runs on multiple platforms – Windows, Linux, iOS, and HTML5, all from the same engineering environment.
High Performance Graphics
High Performance Graphics allows your operators to quickly find and focus on the issues they need to respond to in order to keep your processes running at top efficiency.
Easily modify symbols to include as little or much animation as you like.
Animation and State
Easily customize symbols to show state based on incoming or calculated values, in real-time.
Alarms and Alarm History
Built in Alarm Management, Alarm History, Alarm Acknowledgement make alerting and recording your alarms super easy.
- Easily customize what you want to show.
- Show alarms on screen, or in a report
- Acknowledge and / or Silence alarms
- Use Alarms to alert maintenance, management, or anyone via options for on-screen messages, emails, SMS (text), even Voice Alerts – all built in!
Pop-Up Context Windows
Easily provide context information via pop-ups, tool-tips, trends, charts, or entire screens.
Customizable Trend Charts
Powerful chart customizations are made easy with Tatsoft’s trend chart configuration interface.
Built-in date selectors, zoom-in/out, highlight pen, show/hide pens, multiple-axes and more!
Reports
Easily generate reports on-demand or on a schedule.
Include real-time up-to-date charts and data grids when the reports are run.
Easily customize the report layout to meet regulatory layouts.
View, Save, or e-mail reports – all from within your project!
System & Project Information
Access project and client information easily from within your project. Any item in a client, server, or project is easily usable and viewable as you need.
You could use this information to help drive security (for example, who can see what), track connections (IP, Computer name, etc), and more!
